Rod Mill

Rod Mill

Processing ability: 0.5–500 t/h

Feeding size: ≤25 mm

Applied material: cement, silicate, new-type building material, refractory material, fertilizer, ore dressing of ferrous metal and non-ferrous metal, etc.

  • Gold Ore
  • Quartz
  • Cement Clinker
  • Iron Ore
  • Copper Ore

If you are interested in our products, Click Here for the Latest Discount

Classification:

Rod mill has two available types: dry and wet type, customers can choose a suitable type according to their actual situations. For the processing of quartz sand, dolomite, monazite and other products, it can be equipped with magnetic separator to remove iron.

Rod Mill

Features:

1. Power saving.

2. Advanced controllable discharging technology, more uniform discharge grain size and higher yield.

3. It is applicable to different hardness (Mohs hardness 5.5~12) ore.

4. Adjustable discharging fineness.

Rod Mill Price and Manufacturer

Henan Hongxing Mining Machinery Co., Ltd. is a large-sized joint-stock enterprise integrated with the scientific research, production and sales of heavy mining machinery, which come the first on the list among rod mill manufactures in Henan Province. As one of the largest rod mill manufactures in Central Plain area, Hongxing Machinery has been engaged in the R & D and production for many years. We have rod mill for sale, we not only can provide all kinds of rod mills, but also rod mill accessories for customers. The rod mill price of our company is reasonable and favorable.

Rod Mill Production Site

Hongxing Machinery has formed a strong comprehensive technical innovation system after many years of accumulated experience and development. Along with the processing, processing, assembly, testing and maintenance, packaging, shipping, complete advanced production equipment and large-scale production capacity.

Rod Mill Technical Data

Model
Shell Specifications (mm)
Shell rotation speed
(r/min)
Feeding size
(mm)
Discharging size
(mm)
Processing capacity
(t/h)
Power
(kw)
Total weight
(t)
Diameter Length
MBS0918 900 1800 36-38 ≤25 0.833-0.147 0.62-3.2 18.5 5.9
MBS0924 900 2400 36 ≤25 0.833-0.147 0.81-4.3 22 6.7
MBS1224 1200 2400 36 ≤25 0.833-0.147 1.1-4.9 30 13.9
MBS1530 1500 3000 29.7 ≤25 0.833-0.147 2.4-7.5 75 19.8
MBS1830 1830 3000 25.4 ≤25 0.833-0.147 4.8-11.6 130 34.9
MBS2130 2100 3000 23.7 ≤25 0.833-0.147 14-35 155 46.5
MBS2136 2100 3600 23.7 ≤25 0.833-0.147 19-43 180 48.7
MBS2430 2400 3000 21 ≤50 0.833-0.147 25-65 245 59.7
MBS2736 2700 3600 20.7 ≤50 0.833-0.147 32-86 380 92.5
MBS2740 2700 4000 20.7 ≤50 0.833-0.147 32-92 400 95
MBS3245 3200 4500 18 ≤50 0.833-0.147 64-180 630 149
