Processing capacity: 12-1000t/h
Discharge opening: 3-60mm
Feeding size: 35-300mm
Applied material: barite, marble, talcum, calcite, dolomite, fluorite, kaoline, coal, gypsum, etc.
Cone crusher structure is composed of the main part such as frame body, adjusting device, adjusting sleeve, crushing cone, transmission device and eccentric sleeve as well as electrical, lubrication and other auxiliary parts. It can be used for crushing ore and rock with not more than 250MPa compressive strength, which can be used for crushing hard and medium hard materials in mining, metallurgy, building materials, chemical industry and other departments.
The device adopts the spring overload protection device to make iron and other impurities passing through the crushing cavity without damaging the machine.
Cone crusher is divided into coarse crushing cone crusher, medium crushing cone crusher and fine crushing cone crusher. According to the types of crushing chamber, it can be classified into three categories: the standard type, medium type and short head type, wherein the standard type can be applied to medium crushing; medium crusher suitable for fine and medium crushing; short head is suitable for fine crushing.
1. It adopts hydraulic spring protection device to make iron and other impurities passing through the crushing cavity without damaging the machine.
2. Many kinds of crushing chamber, flexible applications, strong adaptation.
3. Unique dust proof sealing structure, so that dust and other impurities cannot enter the machine, so as to keep the lubricating oil clean.
4. Reliable structure, big crushing ratio, high production efficiency.
5. Less consumption of wearing parts, low operation cost.
6. High degree of automation, reduce downtime.
Hongxing Machinery is professional in the production of cone crusher, which has advanced structure, high quality and complete models, such as Hydraulic Cone Crusher, Mini Cone Crusher, etc. in addition, we also has Cone Crusher Parts for sale. Welcome new and old customers to contact us!
| Specification | Model | Diameter of large end of crushing cone (mm) |
Max.feeding size(mm) |
Width of discharge opening (mm) |
Processing capacity (t/h) |
Motor power (kw) |
Total weight （t） |
Dimensions (L×W×H) （mm） |
| Φ600 | PYB600 | 600 | 65 | 12-25 | 40 | 8P 30 | 5 | 2234×1370×1675 |
| PYD600 | 35 | 3-13 | 12-23 | 5.5 | 2234×1370×1675 | |||
| Φ900 | PYB900 | 900 | 115 | 15-50 | 50-90 | 8P 55 | 11.2 | 2692×1640×2350 |
| PYZ900 | 60 | 5-20 | 20-65 | 11.2 | 2692×1640×2350 | |||
| PYD900 | 50 | 3-13 | 15-50 | 11.3 | 2692×1640×2350 | |||
| Φ1200 | PYB1200 | 1200 | 145 | 20-50 | 110-168 | 8P 110 | 24.7 | 2790×1878×2844 |
| PYZ1200 | 100 | 8-25 | 42-135 | 25 | 2790×1878×2844 | |||
| PYD1200 | 50 | 3-15 | 18-105 | 25.3 | 2790×1878×2844 | |||
| Φ1750 | PYB1750 | 1750 | 215 | 25-50 | 180-360 | 8P 160 | 50.3 | 3910×2894×3809 |
| PYZ1750 | 185 | 10-30 | 80-210 | 50.3 | 3910×2894×3809 | |||
| PYD1750 | 85 | 5-13 | 60-180 | 50.2 | 3910×2894×3809 | |||
| Φ2200 | PYB2200 | 2200 | 300 | 30-60 | 420-700 | 8P 280-260 | 80 | 4622×3302×4470 |
| PYZ2200 | 230 | 10-30 | 130-410 | 80 | 4622×3302×4470 | |||
| PYD2200 | 100 | 5-15 | 80-200 | 81.4 | 4622×3302×4470 |
| Specification | Max.feeding size(mm) |
Processing capacity (t/h) |
| Φ600 | 65 | 40 |
| 35 | 12-23 | |
| Φ900 | 115 | 50-90 |
| 60 | 20-65 | |
| 50 | 15-50 | |
| Φ1200 | 145 | 110-168 |
| 100 | 42-135 | |
| 50 | 18-105 | |
| Φ1750 | 215 | 180-360 |
| 185 | 80-210 | |
| 85 | 60-180 | |
| Φ2200 | 300 | 420-700 |
| 230 | 130-410 | |
| 100 | 80-200 |
Please tell us your materials, capacity and finished product design, we can offer better service for you. Contact Email: sales@hxjq.com
